238 CC | 3B Craft

238 CC – Data sheet

238 CC – SPECS

Overall length: 7,25 m
Maximum beam: 2,55 m
Maximum horsepower: 2 x 200 HP / 1 x 350 HP
Fuel capacity: 390 l
Maximum persons capacity: 6
CE navigation category: B

STANDARD MECHANICAL AND ELECTRICAL FITTING

General electrical system

Electrical system 12 V
General electrical panel inside
Helm panel with switches
2 x 100 Ah batteries
n° 3 battery switches
Battery parallel
Compass 3”

Fuel system

Stainless steel fuel tank – capacity 390 l
Fuel level indicator
n° 1 fuel filler cup

Bilge pump system

n° 2 automatic bilge pumps
n° 1 manual bilge pump

Steering system

Pump for hydraulic steering
Ships’ wheel

Safety

n° 3 manual dry fire extinguishers
Remote-controlled fuel tank closing system

Complete system of zincs for galvanic current

STANDARD OUTDOOR FITTING

Hull

Gel coat
Hand-laid fiberglass with vinyl ester resin skin coats
Termanto cored topsides
Solid fiberglass bottom
Antifouling bottom paint
PVC rubbing strake

Deck

Gel coat
Hand-laid fiberglass
Termanto core

Structures

Ply-Foam stringer system
Plywood bulkheads

Navigational lights

Navigational lights
Stainless steel support for 360° light
Radar reflector

Cockpit and deck fitting

T-Top with fiberglass top on a stainless steel structure
Lights fore and aft
Glued tempered glasses
Bow stainless steel handrails
Bow plate
n° 6 stainless steel mooring cleats
n° 8 stainless steel built-in rod holders
Acoustic warning signal
Side access door in console
Pilot console
Cockpit unit with helm seat
Bow bench with cushions
Cockpit paddings
Courtesy lights
Cockpit storage with tub for fish
Stainless steel boarding ladder
Self-draining cockpit
Transom fish box with pump
Transom door with tuna gate
Non-skid surface on bridge deck and cockpit

OPTIONAL EQUIPMENT

5-stainless steel rod holders on the fiberglass T-top
Electrical windlass 500 W with anchor and 50 m zinc plated chain Ø 6
Battery charger 25 Ah with cable with dockside power and current taps 220 V
n° 2 cockpit sockets 12 V
Hydraulic trim tabs system 12 V with stainless steel plates and digital trim tabs indicators
Bow sundeck
Bow table in teak
Opening stern bench with cushion
AM/FM stereo with CD and 4 speakers
Cockpit sea water pump
Fresh water kit (water tank – capacity 50 l, level indicator, filler cup, water pressure system pump, sink, tap and fresh water shower in the cockpit)
Windshield wiper with washer
Electrical toilet with waste system with holding tank, level and filter
Custom hull GELCOAT colour (when different from white)
